42m Flying Sky

A 42m flying sky is two rides on one ticket. By day it is a thrill: 32 visitors lifted to 29.5 m and swung outward at 10 r/min. After dark it becomes a viewing ride, and that second shift is where the investment starts to look different.

It stands 39 m, ships in five 40HQ containers and puts about 39.6 t on the site.

Thrill by day, view by night

Most thrill rides earn once, during opening hours. The flying sky earns twice, because the view that scares teenagers in the afternoon is the view couples pay for after dark.

The night lighting package turns the same machine into an evening attraction. For destinations that run late opening, evening events or a night market, that second window can carry a large part of the payback.

The dynamic sweep decides your site plan

The static slewing diameter is 14.3 m and the dynamic diameter is 22.7 m. Plan the fence, the queue and the landscaping around the larger figure, because the gondola travels past the static ring every turn.

Then give it a view. A waterfront edge, a hillside or the far side of a lake multiplies what the ride is worth, and a low position wastes the 29.5 m operating height.

Power, weight and what the site has to carry

Lifting power is 45 kW and the rotation runs on 4 x 7.5 kW, so the installed load is spread across the lift and the swing. Confirm the substation capacity and the cable route before the foundation is poured.

At about 39.6 t across five containers, the base is a real civil item. Order the foundation drawing with the ride and have it reviewed by a local engineer alongside your planning submission.

Delivery: five containers and one crane week

1. Prepare the base before the containers land

   Foundation, anchor bolts and the cable route ready and checked. This is the step that delays projects when it slips.

2. Book one crane window

   Five containers arrive together and the sections are lifted in sequence. Keep the access road clear for the truck and the crane.

3. Assembly, wiring and the test run

   The factory test is repeated on site, then the control system is set for your supply.

4. Lighting commissioning after dark

   The lighting package is adjusted in the dark, so the ride looks right from the walkway rather than only in daylight.

Where a 42m flying sky makes money

Scenic areas, waterfront developments and night tourism destinations get the most out of this ride, because they already have the audience that pays for a view. Theme parks use it as a signature attraction next to the gate.

If your site cannot take five containers and a 39 t base, the 25-seat giant pendulum delivers a comparable thrill on a lighter civil footprint, and the 35m rotating tower reaches a similar height with three containers.

Questions buyers ask about the 42m flying sky

Technical reference: 32 riders / rotation 10 r/min / lifting speed 0.75 m/s / slewing diameter 14.3 m static and 22.7 m dynamic / operating height 29.5 m / structure height 39 m excluding the lightning rod / lifting power 45 kW / rotation power 4 x 7.5 kW / about 39.6 t / 5 x 40HQ.

Part of the thrill rides range built by DINIS.
