Amusement park carousel for sale has been a must-have facility for most amusement park since before. Even now it still plays an important role in amusement park. If you are thinking of having a carousel ride in your amusement park.This passage might offer you some help.
Today we will shed light on some details for amusement park carousel for sale. About how does a carousel operate. How to choose a carousel for amusement park,its engine system. And how to maintain smooth operation of amusement park carousel for sale in post novel corona virus era.
Table of Content
How does an amusement park carousel operate?
The working principle of the upper drive carousel is as follows:
After starting. First, the power source motor drives the large belt pulley on the input shaft of the reducer to drive the reducer. Then the output shaft of the reducer rotates the transition shaft and the pinion installed on the upper end through the coupling (or a pair of bevel gears). The pinion gear meshes with the large gear transmission installed on the main shaft. Following the main shaft drives the entire turntable to rotate through the columns on the inner and outer sides of the truss.
When the truss rotates, the conical large gear installed on the top of the main shaft rotates together. The conical pinion on the inner end of the crankshaft installed on the truss meshes with the conical large gear drive the crankshaft to rotate. When the crankshaft rotates, it drives the tie rod mounted on itself to move up and down. Because the horse hangs under the lever, the horse moves up and down. At the same time,the turntable connect with the rod at the lower end of the horse through the sleeve. And the horse rotates together with the turntable. Therefore, the rotating motion and the up and down motion of the horse combine themselves together. And thereby forming the jumping motion form of the horse.
[/one_half]
- Area needed: 6 meter
- Voltage: 380V
- Power: 4kw
- Height: 6 m
- Capacity: 3/6/12/16/24/36 person
- Notes: Specification below is just for reference. Email us for the detail information.
Small carousel’s up and down motion function theory
In addition, for a small carousel. Its rotational motion is driven by the motor through the triangle to drive the worm gear reducer.The reducer is connected to the tire to drive the tire to rotate. After that the tire drives the turntable to rotate through friction.So the motor motivates the up and down movement of the carousel through the chain. And the chain drives the sprocket to run. Then the sprocket is connected with the worm gear reducer through the shaft and the universal joint. Therefore, the operation of the sprocket drives the movement of the reducer. The reducer drives the movement of the crankshaft, and the crankshaft drives the tie rod to realize the up and down movement of the carousel.
The movement form of the lower drive carousel is different from that of the upper drive carousel. It consists of two parts: the rotating movement of the turntable and the up and down movement of the carousel.
- Allowable Passenger: >10
- Voltage: 220v/380v
- Power: 1.5kw/3.5kw/3kw/4kw
- Area Size: 1.5m/5.5m
- Notes: Specification below is just for reference. Email us for the detail information.
The rotation of the turntable moves like this:
- Technical Parameters
- Voltage: 220v/380v
- Power: 1.5kw/3.5kw/3kw/4kw
- Area Size: 1.5m/5.5m
- Capacity: 3/6/12/24/36 Passengers
- Notes: Specification below is just for reference. Email us for the detail information.
How to choose your amusement park carousel for sale?
First,there are a few clues you need to consider, for example,the specification the client provide,your budget for a merry go round,the space you design for it,and so on.
- Area needed: 3m*5m
- Voltage: 380V
- Power: 2.2kw
- Height: 3.5m
- Capacity: 3/6/12/16/24/36 person
- Notes: Specification below is just for reference. Email us for the detail information.
- Capacity:12/24 persons
- Diameter: 5.5m Voltage: 220V/380V
- Power: 4kw
- Height: 5.5m
- Horse Loading: 120-150KG
- Notes: Specification below is just for reference. Email us for the detail information.
Operation model
If it is in a fixed venue, we might suggest to choose the upper transmission carousel. Although it is expensive, it is of good quality and beautiful craftsmanship, attracting more tourists. No matter which one you choose, we suggest you shop around to choose the most suitable one.
The engine system of amusement park carousel for sale
Here’ re the factors to consider when choosing an engine system for your merry go round:what is its maximal speed of the merry-go-round? Given that your motor engine is more powerful,your merry-go-round’s ability to reach and maintain the maximum speed is more notable. Besides, battery capacity and voltage is at play. This’ ll be needed during the ignition stage. However, the battery capacity will depend on the size of your merry-go-round. And according to your budget.There are various engine systems of a merry-go-round and with different expenditure. So, you must make your choice within the cost range you are likely to fit in.
Normally manufacturer will offer you these engine options any time you go purchasing a merry go round:Solar powered Engine: It is the best option if your park is ample in total solar radiation and have ample mount of sunshine. It will save you costs associated with purchasing fuel and electricity bills. It is an environment friendly choice. The electric powered engines are efficient and require minimal expertise to operate. In contrast, gasoline engines are cheap, yet it may cause environmental harm as well.
In post novel coronavirus era,how to maintain smooth operation of amusement park carousel for sale.
This year marks the fourth year of the pandemic outburst.It influenced most of the industry. Don’t be afraid of economic downturn. We should come up with our own solution to offset the toll it brings to us. To avoid intermittent pandemic interrtuption,we suggest you examine everyone of your clients’ safety identification in case mass gathering cause infection in your amusement park since it is a public place.
There is a great number of customer traffic coming and going everyday. You should pay special attention to it. You can prepare some medical masks and hand sanitizer for customers to use. What’s more, these protective measures taken by your amusement park can denote that you are a responsible for your customers’ safety. Another important thing you should understand is that lower your expectations at first and trust yourself a bit more. It is a long process before you make your expected results. We believe that with right management strategies,som e determination to overcome the difficulties,and reliable merry go round manufacturer’s help like us. You will see satisfying outcome sooner or later.
In summary,we lead you in how does a carousel operate. How to choose your amusement park carousel for sale. The engine system of amusement park carousel for sale. In post novel corona virus era. How to maintain smooth operation of amusement park carousel for sale. All in all, hope you can get a more general picture for amusement park carousel for sale by this passage.
Hot antique merry go round horse for sale technical parameters
Notes: Specification below is just for reference. Email us for the detail information.
| Seats Info | Occupied Area | Voltage | Power | Speed | Diameter | Working Principle |
|---|---|---|---|---|---|---|
| 3 Seats | Φ1.5mx1.5m | 220v/380v/customized | 500w | 0.8m/s | 1.4m | Upper/Lower/Imitated Transmission |
| 6 Seats | Φ3mx3m | 220v/380v/customized | 1.1kw | 0.8m/s | 3.3m | Upper/Lower/Imitated Transmission |
| 12 Seats | Φ6.5mx6.5m | 220v/380v/customized | 3kw | 0.8m/s | 5.3m | Upper/Lower/Imitation Transmission |
| 16 Seats | Φ8mx8m | 220v/380v/customized | 3.3kw | 0.8m/s | 6m | Upper/Lower/Imitation Transmission |
| 24 Seats | Φ9mx9m | 220v/380v/customized | 6kw | 1.0m/s | 8m | Upper/Lower/Imitation Transmission |
| 36 Seats | Φ10mx10m | 220v/380v/customized | 7kw | 1.0m/s | 9.5m | Upper/Lower/Imitation Transmission |
| double deck | Φ10m*10m | 220v/380v/customized | 6kw | 0.8m/s | 8m | Upper/Lower/Imitation Transmission |
